10um Titanium Sintered Porous Metal Filter Cartridge Factory produces rigid porous elements via cold isostatic pressing followed by high‑temperature vacuum sintering of high‑purity titanium powder (≥99.60%). This processing route yields a monolithic filter medium-entirely free of welds or seams-which removes structural weak points and provides dependable performance under severe vibration and fluctuating pressures typical of upstream oilfield and chemical service. The resulting 10‑micron absolute‑rated cartridge exhibits a narrow pore size distribution and porosity in the 35‑50% range, with an open‑cell network that supports surface‑type filtration. Such geometry enables rapid formation of filter cake, maintains high permeability at the onset of service, and allows effective regeneration through back‑pulse cleaning. Temperature tolerance spans from cryogenic levels up to 280°C, without compromising mechanical integrity under repeated thermal and pressure cycling. The GR1 pure titanium composition offers notable resistance to intergranular corrosion, oxidation, and attack by aggressive media-an advantage particularly evident in chloride‑bearing brines and acidic process streams where conventional 316L grades quickly show degradation.

In practical service, this sintered porous titanium cartridge proves equally effective for solid‑liquid separation in low‑viscosity streams containing rigid particulates, and for gas filtration at elevated temperatures or in corrosive atmospheres. Field data indicates that the filter element endures over 10,000 reverse‑flow back‑pulse regeneration cycles with no measurable media fatigue or pore blinding-a durability that extends replacement intervals and significantly lowers total cost of ownership. Initial pressure drop at rated flow remains typically below 3 kPa, reflecting an optimized pore architecture that balances low energy consumption against high dirt‑holding capacity. When integrated into multi‑stage filtration trains, the cartridge works in tandem with titanium rod filters-functioning either as a pre‑filter to safeguard downstream membranes, or as a polishing stage for critical product streams. Common deployment scenarios include decarburization filtration in pharmaceutical manufacturing, catalyst recovery in petrochemical units, guard filtration for refinery effluents, and high‑purity gas polishing where even trace media migration would be unacceptable. Each application benefits from the predictable performance and long‑term reliability that come from a well‑controlled sintering process and consistent material quality.

Products Parameters

0-8um-micron-titanium-sintered-porous-metal77bf5ebf-bc0c-434b-b1a4-ad00b449f7b1

Material	GR1 titanium powder
Pore size	10um
Diameter	30mm
Connection	Customized by drawing
Technique	Sintering

GR1 titanium chemical element(%)

AI	0.001	Si	<0.001
Cr	0.001	C	0.006
Fe	<0.001	O	0.027
Mn	<0.001	H	0.001
CI	0.059	N	0.002
Ni	<0.001

Products Features

Efficient Filtration: The 10um Titanium Sintered Porous Metal Filter Cartridge features a precise 10-micron aperture design, enabling effective removal of tiny particles and impurities from liquids and gases, ensuring excellent filtration performance.

High-Temperature Resistance: This filter cartridge can operate at temperatures up to 280℃, making it suitable for filtration applications in extreme temperature environments.

08um Micron Titanium Sintered Porous Metal Filter Cartridge 3

Strong Pressure Resistance: Manufactured using titanium powder sintering, the 10um Titanium Sintered Porous Metal Filter Cartridge offers exceptional pressure resistance, withstanding high-pressure conditions and ensuring the reliability and longevity of the filtration system.

Excellent Chemical Stability: Made from titanium metal, this filter cartridge exhibits outstanding chemical stability, withstanding corrosive chemicals such as strong acids and alkalis, making it suitable for handling aggressive liquids and gases.

Products Applications

1. Titanium sintered porous metal filter cartridges offer unparalleled strength and durability, making them an excellent choice as a high-pressure filter medium in various industrial applications, including oilfield oil sands separation. Their robust construction ensures long-lasting performance in demanding environments.

2. These filter cartridges find widespread use in machinery, ships, and other equipment for filtering fuel, lubricating oil, and hydraulic start oil. With exceptional corrosion resistance, they are specifically designed to thrive in harsh industrial settings, providing reliable filtration for optimal equipment performance.

3. Titanium sintered porous metal filter cartridges play a vital role in the chemical industry, where they are employed in chemical plants for filtering and processing diverse substances. Their remarkable chemical resistance and stability make them highly suitable for demanding chemical processing applications, ensuring efficient and safe operations.

What is Machine Maintenance? Definition & Examples | NEXGEN Shipbuilding | OECD Natural Gas Filter Separator Systems | How They Work

4. The high-temperature resistance of titanium sintered porous metal filter cartridges makes them an ideal choice for high-temperature gas dust removal applications. Moreover, their superior filtration performance extends to filtering food and medical substances. These cartridges deliver reliable and precise filtration results, meeting the stringent requirements of these critical industries.

5. Water treatment and distribution systems, gas distribution systems, and fluidized bed applications benefit from the exceptional filtration performance and durability of titanium sintered porous metal filter cartridges. These cartridges provide reliable and efficient filtration, ensuring the purity and quality of water, gas, and fluidized materials in various industrial processes.
