Micro porous Filter Disc Titanium Fine Filtration

Customized titanium sintering microporous filter disc is a microfiltration element made of industrial high-purity titanium powder (99.6%) as raw material, sieved and formed by sintering. Due to its high-tech material composition and special molding process, titanium powder sintered filter material has unique and excellent performance.

Titanium-sintered porous disc products are widely used in chemical, petroleum, metallurgy, aviation, natural gas, electronics, automotive, medical, disinfection, beverage, environmental protection, and other fields.

customized titanium filter disc

sintered porous titanium disc

Parameters:

Product name: Customized titanium sintering microporous filter disc

Process style:isostatic pressing ,molding,sintering,machining

Porosity:35%

Aperture:2.5-160 (μm)

Filtration precision:0.2-100 μm

Grade:GR1,GR2,Gr5,Gr7,Gr12 etc

Filtration efficiency:98%

Compressive strength:2-3Mpa/cm2

Shape: plate\ disc\tube

Thickness: 0.3-60mm
Max width: 200mm
Max Length: 1000mm

Processing: sintering

Features:

1. This material has a different pore size and filtration accuracy (0.2um-80um), crisscrossing the channel, and high filtration separation efficiency.

2. High-temperature resistance, and thermal shock resistance. Suitable for use in the temperature range of -200-300 °C.

3. Anti-corrosion, suitable for a variety of depth separation and fine filter of acid, alkali, and another corrosive medium.

4. With a specialty of metal or alloy, absorbing energy, absorbing noise, heat resistant, shockproof, buffer, high thermal conductivity, electrical conductivity, good strength, good toughness, suitable for high-pressure environment.

5. Welding available and simple machining, easy loading and unloading.

6. Stable hole shape, and homogeneous distribution, ensuring the stability of the filter performance.

7. Good regeneration properties, the filter performance recovery of the regeneration is more than 90%.

Processiong:

Packaging and shipping Details:

1. inner packing: plastic foam bag;
2. outer packing: plywood case with strips;

3. We ship worldwide by EMS, DHL, UPS, FedEx, TNT, and so on;

4. We shall be boxed, crated, banded on skids, or bundled in such a manner as to assure safe delivery to its destination;

Details

TopTiTech's main products are Sintering Titanium Powder Filters, Titanium Sintered Filter Sheets, Titanium Fiber Felt, Titanium Foil, Titanium Anode, Titanium Aeration Heads, Porous Sintered Titanium Filter Tubes, Stainless Steel Powder Sintered Filter Tubes, Stainless Steel Sintered Wire Mesh, and so on.

Now we have gained close cooperation with clients from Korea, Iran, Europe, and America, and won good comments and suggestions from our users.

TopTiTech can design and produce corresponding specifications and models of filter equipment for the different needs of each user, which has implemented relevant national standards for production, testing, packaging, transportation, and recovery. At the same time, our company has been operating various specifications of titanium and titanium alloy pipes, bars, plates, and wires, as well as titanium standard parts and titanium products. TopTiTech warmly welcomes new and old customers to visit and negotiate

business.

Welcome to inquire, and we will answer your questions in detail and have detailed information available on request.
