TOPTITECH's PM-35 Ventilated Breathable Steel For Injection Mold Application is a high-performance porous metal material specifically designed to address gas entrapment issues in injection molds. With a porosity rate of 30-35% and a uniform pore size distribution of 5-10 micrometers, PM-35 ensures efficient gas permeability while maintaining the structural integrity required for high-pressure molding applications. This material is manufactured using advanced powder metallurgy techniques, incorporating stainless steel alloys such as chromium, nickel, manganese, and molybdenum, which provide exceptional strength, hardness, and corrosion resistance. By integrating PM-35 into mold designs, manufacturers can significantly reduce injection pressure, shorten cycle times, and eliminate defects such as burn marks, flow lines, and warping, thereby enhancing product surface quality and yield rates.

PM-35 Ventilated Breathable Steel For Injection Mold Application 3

Customizable to client specifications, PM-35 Ventilated Breathable Steel is ideal for creating mold inserts, cores, and other critical components. Its interconnected microporous structure allows for uniform gas diffusion, preventing localized gas buildup and ensuring consistent mold performance. The material's high thermal conductivity and wear resistance make it suitable for demanding applications in automotive, aerospace, and consumer goods industries. PM-35's ability to mitigate internal stresses and reduce post-processing requirements further enhances production efficiency and cost-effectiveness. For optimal performance, PM-35 is processed using soft machining techniques such as wire EDM and laser cutting, followed by specialized surface treatments to restore and maintain its permeability. This precision-engineered solution offers a reliable, long-lasting answer to complex mold venting challenges.

Products Specifications

Material	SS316L
Filtration grade/Pore size	5-10um
Size	97475.0mm customized by the drawings
Porosity	30%-35%
Technique	Sintering

Products Features

PM-35 Ventilated Breathable Steel For Injection Mold Application 2

30-35% Porosity with 5-10µm Pore Size: PM-35's uniform microporous structure ensures consistent gas permeability, effectively eliminating gas entrapment and reducing injection pressure by up to 20%. This results in fewer defects such as burn marks, flow lines, and voids.

Enhanced Mold Performance: By integrating PM-35, cycle times are reduced by 15-25%, improving production efficiency. The material's high thermal conductivity stabilizes mold temperatures, minimizing warping and dimensional instability in finished products.

Superior Mechanical Properties: Composed of chromium, nickel, manganese, and molybdenum alloys, PM-35 delivers exceptional tensile strength (≥800 MPa) and hardness (HRC 28-32), ensuring durability under high-pressure molding conditions.

PM-35 Ventilated Breathable Steel For Injection Mold Application 3

Reduced Post-Processing: PM-35 eliminates the need for additional venting systems, such as vents or ejector pins, reducing mold complexity and maintenance costs. Its ability to dissipate internal stresses decreases part deformation, lowering post-machining requirements by 30%.

Corrosion and Wear Resistance: The stainless steel composition provides excellent resistance to chemical corrosion and abrasion, extending mold lifespan by up to 40% compared to traditional mold steels.

PM-35 Ventilated Breathable Steel For Injection Mold Application 1

Customizable Solutions: PM-35 can be tailored to client specifications, including size, shape, and porosity, ensuring optimal performance for specific applications in automotive, aerospace, and consumer goods industries.

Energy Efficiency: The material's gas-permeable design reduces clamping force and energy consumption by 10-15%, contributing to sustainable manufacturing practices.

Improved Surface Finish: PM-35 enables high-quality surface finishes, particularly for textured or matte parts, by preventing gas-related defects and ensuring uniform material flow.

PM-35 Ventilated Breathable Steel For Injection Mold Application 4

Easy Maintenance: PM-35's microporous structure can be restored using soft machining techniques like wire EDM or laser cutting, followed by ultrasonic cleaning, ensuring long-term permeability and performance.

Cost-Effective Production: By reducing scrap rates, shortening cycle times, and minimizing downtime, PM-35 lowers overall production costs by up to 25%, making it a cost-efficient solution for high-volume manufacturing.

applications

Automotive Industry: PM-35 is widely used in manufacturing complex automotive components such as dashboards, door panels, and light housings. Its gas-permeable properties prevent defects like burn marks and flow lines, ensuring high-quality surface finishes and dimensional accuracy.

Consumer Electronics: The material is ideal for producing intricate plastic parts for smartphones, laptops, and wearables. PM-35's uniform porosity eliminates gas entrapment, reducing scrap rates and improving production efficiency by up to 20%.

Aerospace Components: The material's high strength-to-weight ratio and thermal stability make it perfect for aerospace applications, such as cabin interiors and lightweight structural parts. PM-35 ensures consistent performance under extreme conditions.

The Prospects for the Development of the Automotive Industry

Optical Components: The material is suitable for molding lenses, light guides, and reflectors. PM-35's ability to maintain consistent mold temperatures minimizes optical distortions and improves product clarity.

Custom Mold Solutions: PM-35 can be tailored to specific client requirements, making it versatile for niche applications such as prototyping, low-volume production, and high-precision molding.

Packaging Industry: PM-35 is employed in producing thin-walled packaging containers and lids. Its ability to reduce injection pressure and cycle time enhances productivity while maintaining part integrity.

Industrial Equipment: The material is used for molding durable parts like gears, housings, and connectors. PM-35's wear resistance and mechanical strength extend the lifespan of industrial molds by up to 40%.

Toy Manufacturing: PM-35 ensures high-quality finishes for toys with intricate designs and textures. Its gas-permeable structure prevents defects, reducing post-processing and improving cost efficiency.

The Simple Way the Packaging Industry Can Increase Production Capacity :: Viking Masek

Solutions for Restoring Permeability in PM-35 Ventilated Breathable Steel

Over time, the permeability of PM-35 Ventilated Breathable Steel may degrade due to clogging or contamination. Below are professional solutions to restore its performance:

Plastic Residue or Tar Clogging: If micro-pores are blocked by plastic debris or tar, apply a suitable plastic-dissolving solvent. Allow it to sit for one hour, then use high-pressure air to clear the pores and verify permeability.
Oil Contamination from Mold Additives or Release Agents: Clean the surface with acetone or a similar solvent to remove oil-based contaminants. Follow up with high-pressure air to test the restored permeability.
Advanced Restoration with Soft Machining: If the above methods fail, employ soft machining techniques such as wire EDM or laser processing to repair the surface. After machining, clean the material with acetone and ensure it is completely dry before reuse.
Addressing Flow Marks or Stains: Flow marks and stains are often caused by factors such as inadequate venting, improper cold slug well design, gate geometry, mold temperature, or material properties. While PM-35 effectively resolves venting issues, other factors require separate analysis and adjustments to the mold design or process parameters.
